banana pedals Bananana Aurora Multi Delay – Motor City GuitarA delay pedal with eight modes, allowing flexible control over pitch, speed, and playback direction. With features such as chromatic pitch shift delay, delay at 2x and 4x speed, reverse delay at x, 1x and 2x speed, and 2x speed trigger delay that automatically samples and loops your previous phrase when triggered by a break in the input sound, this delay pedal will enable you to create experimental and radical sounds. 8 MODES: Pitch Up This delay

A delay pedal with eight modes, allowing flexible control over pitch, speed, and playback direction.

With features such as chromatic pitch shift delay, delay at 2x and 4x speed, reverse delay at ½x, 1x and 2x speed, and 2x speed trigger delay that automatically samples and loops your previous phrase when triggered by a break in the input sound, this delay pedal will enable you to create experimental and radical sounds.


8 MODES:

Pitch Up
This delay increases the pitch on each repeat.
The pitch shift can be set chromatically between +1 to +12.
Each time the pitch setting changes, the “Mode” knob flashes green.
(It flashes white at the fifth and octave intervals only).

Pitch Down
This delay decreases the pitch on each repeat.
The pitch shift can be set chromatically between -1 to -12.
Each time the pitch setting changes, the “Mode” knob flashes green.
(It flashes white at the fifth and octave intervals only).

Speed Up
A delay that replays sampled sound at a multiple of the original speed.
Playback speed can be selected from 2x and 4x.
With the time set to 0, it can also be used like a pitch shifter.

Speed Up Trigger
Automatically samples and loops the previous phrase when triggered by a break in the input sound.
Playback speed can be selected from 2x and 4x.

Reverse
A delay that plays back a sampled sound in reverse.
Playback speed can be selected from ½x 1x and 2x.

Cascade Reverse
A delay that reverses the playback direction of the sampled sound each time it feeds back into the pedal.
Playback speed can be selected from ½x 1x and 2x.

Multi Reverse
A delay that plays back a sampled sound in reverse.
The sample is played back at 1/2x, 1x and 2x speed simultaneously.
The balance of 1/2x & 2x sampled sound can be controlled using the “Func” knob.

Reverse Trigger
Automatically samples and loops the previous phrase in reverse when triggered by a break in the input sound.
Playback speed can be selected from ½x 1x and 2x.


Controls:

Tail ON/OFF
Selects keeping the tail when the pedal is bypassed or not

Mode
• Pitch Up
• Pitch Down
• Speed Up
• Speed Up Trigger
• Normal Reverse
• Cascade Reverse
• Multi Reverse
• Reverse Trigger

Repeat
Controls the delay repeats
(Not used when Speed Up Trigger Mode & Reverse Trigger Mode are selected.)

Time
Sets the delay time

Func
Adjust the parameters of each modes

Pitch Up / DownPitch(Chromatic)

Speed Up / Speed Up Trigger
Playing Speed(x2, x4)

Reverse / Cascade Reverse / Reverse Trigger
Playing Speed(x-1/2, x-1, x-2)

Reverse Multi
Balance(ccw: Emphasize the x-½ tone / cw: Emphasize the x-2 tone)

Vol
Level control for the dry signal

Foot Switch
By press & hold foot switch < 2sec then release, you can toggle dry through or cut.
(blink red = dry through / blink green = dry cut)


SPECIFICATIONS
DIMENSIONS: 2 x 3.7 x 1.9 inches (WxDxH)
WEIGHT: 7.1oz
BYPASS: BUFFERED BYPASS
INPUT IMPEDANCE: 1Mohm
POWER SOURCE: 9V DC(Center negative)
CURRENT DRAW: 60mA
